GXservo 120kg Servo PWM digital Servos:
High torque digital servo shell using aviation aluminum alloy CNC precision manufacturing, aluminum CNC shell metal gears large high torque steel precision gears, brushless motor, high sensitivity, compact body, high voltage circuitry, waterproof and dustproof function, can be slow to start and blocking the protection function; support for free computer parameter adjustment (need to additionally purchase a USB programming card to regulate the parameters), support for free to adjust the pulse width angle.Used in 1/6 of the remote control toy cars, model airplanes, model ships, robotics industry.
| Item | Specification |
|---|---|
| No Load Speed | 6.0V ≤ 0.16sec/60° |
| 7.4V ≤ 0.14sec/60° | |
| 8.4V ≤ 0.13sec/60° | |
| Max. Torque* | 6.0V ≥ 100kgf.cm |
| 7.4V ≥ 120kgf.cm | |
| 8.4V ≥ 135kgf.cm | |
| Pulse Width Range | 500-2500us |
| Dead Band Width | ≤ 2 us |
| Sizes | 60x30x53.65mm |
| Weight | 210g(No Inclidong Accessory) |
| Case Material | Aluminum Alloy |
| Gear Set Material | Metal Gear |
| Motor Type | Brushless Motor |
120kg Brushless Servo For 1/6 RC Cars and Robotics
Product Basic Information
The 120kg Brushless Servo is built to deliver high performance and precision in demanding applications. Designed for both 1/6 scale remote control cars and robotics systems, this servo offers an impressive 120kg.cm of torque, making it ideal for handling heavy-duty loads and providing accurate, responsive control. Whether you’re racing large-scale RC cars or utilizing robotic arms for intricate tasks, this servo offers the power, speed, and reliability you need for superior performance.
- Model: 120kg Brushless Servo
- Torque: 120kg.cm
- Voltage: 7.4V – 8.4V (high voltage operation)
- Motor Type: Brushless Motor
- Gear Material: High-strength metal gears
- Application: Perfect for 1/6 scale RC cars and robotic systems requiring precise control and high torque
- Size: Standard size for 1/6 scale RC cars and robotic arms
- Bearing: Dual ball bearings for smooth and responsive operation
Selling Points
- Impressive Torque: With 120kg.cm of torque, this servo ensures exceptional control and power for large 1/6 scale RC cars and complex robotics systems.
- Brushless Motor for Efficiency: The advanced brushless motor technology offers higher efficiency, longer lifespan, and reduced maintenance compared to traditional brushed motors.
- Durable Metal Gears: Built with high-strength metal gears to handle the heavy-duty use typical of RC and robotic applications.
- High Voltage Compatibility: Supports high voltage operation (7.4V – 8.4V), providing the necessary power for both fast RC car movements and precision robotic actions.
- Smooth and Fast Response: Dual ball bearings ensure minimal friction, enhancing the servo’s responsiveness and making it ideal for both competitive racing and robotics tasks.
Advantages
- Powerful Torque for Heavy-Duty Applications: With 120kg.cm of torque, this servo provides the necessary power for controlling large 1/6 scale RC cars and robotic systems, even under heavy loads or extreme conditions.
- Brushless Motor Technology: The brushless motor offers greater energy efficiency and durability, providing smooth operation with minimal maintenance.
- Durability and Precision: The servo is designed with metal gears and dual ball bearings, ensuring long-lasting performance and precision control.
- Fast Response Time: Ideal for high-speed racing and robotics, where quick response times and precise control are critical.
- Versatility: Suitable for a wide range of applications from RC cars to industrial robotics, offering both performance and reliability.
Application Fields
- 1/6 Scale RC Cars: Perfect for controlling large RC cars, offering powerful steering and precise control for both on-road and off-road use.
- Robotics Industry: Ideal for robotic systems requiring high torque and accuracy for precise movements, such as robotic arms, automation systems, and more.
- RC Racing: A great option for competitive RC racing, where high torque and responsive control are essential for maneuvering at high speeds.
- Off-Road and Heavy-Duty RC Vehicles: Designed to handle rough terrains and challenging environments, ensuring optimal performance in off-road RC cars.
- Industrial Robotics: Perfect for industrial applications that require precise movement and heavy lifting, such as assembly, packaging, and other automation tasks.
Advantages Comparison
| Feature | 120kg Brushless Servo | Standard RC Servo |
|---|---|---|
| Torque | 120kg.cm | 20-30kg.cm |
| Motor Type | Brushless Motor | Brushed Motor |
| Voltage | 7.4V – 8.4V | 4.8V – 6.0V |
| Gear Type | Metal Gear | Plastic Gear |
| Bearing | Dual Ball Bearings | Standard Bushings |
| Speed | Fast and precise | Slower response |
| Durability | High durability, metal gears | Moderate durability |
Usage Instructions
- Pre-Installation Preparation:
- Confirm that the 120kg Brushless Servo is compatible with your 1/6 scale RC car or robotics system, considering size, voltage, and torque specifications.
- Ensure your receiver and ESC (Electronic Speed Controller) can handle the 7.4V to 8.4V voltage range for optimal performance.
- Installation Steps:
- Install the servo in the designated space within your RC car or robotic system, ensuring proper alignment with the steering or control system.
- Connect the servo’s cables to the receiver and ESC, ensuring correct polarity and secure connections.
- Attach the servo horn to the servo’s output shaft securely to avoid any slippage during use.
- Operation:
- Power up your RC car or robotic system and check for proper responsiveness, adjusting the controller settings for smooth and accurate movement.
- Test the servo under various conditions (racing, heavy-duty tasks, robotic precision movements) to verify its torque, speed, and precision.
- Safety Considerations:
- Avoid overloading the servo to prevent damage. Ensure you stay within the torque limits for optimal performance.
- Regularly inspect the servo for signs of wear, especially after extended use or under heavy loads.
- Lubricate the servo if needed to reduce friction and extend its operational lifespan.
Quality and After-Sales Service
- Quality Assurance: The 120kg Brushless Servo undergoes thorough quality testing to ensure high performance and reliability in both RC and robotics applications.
- After-Sales Support: Our dedicated support team is available to assist with installation, troubleshooting, and operational questions, offering expert help whenever you need it.
- Warranty: This servo comes with a 1-year warranty, covering manufacturing defects and functional issues under normal use.
- Long-Term Service: We provide continuous support to ensure your servo remains in optimal condition for long-lasting, reliable performance.
